Traction mobile scissor yog ib qho Txawb Txawb lub rooj loj saws nrog cov txheej txheem zoo hlau, ib leeg daim hlau txuas thiab ob sab sau txoj kev siv tshuab, kev lag luam ntsaws hydraulic chaw nres tsheb lossis kev sib koom ua lag luam hydraulic twj chaw nres tsheb. Lub tshuab ua lub ntaiv tau nruab nrog cov cuab yeej kev nyab xeeb xws li tshuav valve thiab tswj kev ceev ceev. Lub platform muaj kev nyab xeeb, txhim khu kev qha thiab ruaj khov. Cov koob no ntawm cov elevators muaj cov yam ntxwv ntawm hloov kev txav, ruaj khov nqa, thauj khoom muaj peev xwm loj thiab kev ua haujlwm yooj yim. Lawv yog cov dav siv hauv cov chaw ua haujlwm thiab tshuab. Cov teb, cov chaw tsim hluav taws xob, chaw nres tsheb, thaj teb thiab lub tsev kho kom zoo nkauj thiab lwm yam kev lag luam. Yuav tsim thiab tsim khoom raws li tus neeg siv khoom xav tau.
Txawb scissor cov lus zoo: Lub tshuab ua kom lub nraub qaum muaj qhov ua haujlwm ntawm kev tsav tsheb thiab taug kev. Nws tuaj yeem xaiv peb lub hwj huam tswj thiab roj teeb tswj txav. Nws yog hloov tau yooj yim thiab txav tau yooj yim, ua haujlwm rau qhov siab tau yooj yim dua thiab nrawm. Nws tuaj yeem taug kev nrawm thiab maj mam, thiab kho qhov nrawm. Nws yog qhov ua tau zoo thiab kev nyab xeeb ntawm kev lag luam niaj hnub no. Cov khoom siv ua haujlwm zoo hauv tshav dav hlau.
Qauv | Max. platform Qhov siab (m) | Thauj khoom muaj peev xwm | Cov Ntawv Loj （mm) | Zuag qhia tag nrho (mm) | NW (kg) |
500kg Ntsaws muaj peev xwm | |||||
ESL0504 | 4 | 500 | 2100*830 | 2250*950*1100 | 800 |
ESL0506 | 6 | 500 | 2100*830 | 2250*950*1200 | 880 |
ESL0507 | 7 | 500 | 2100*830 | 2250*950*1280 | 970 |
ESL0508 | 8 | 500 | 2100*930 | 2250*1060*1380 | 1050 |
ESL0509 | 9 | 500 | 2100*930 | 2250*1060*1500 | 1165 |
ESL0510 | 10 | 500 | 2100*1230 | 2250*1350*1530 | 1360 |
ESL0511 | 11 | 500 | 2100*1230 | 2250*1350*1650 | 1400 |
ESL0512 | 12 | 500 | 2550*1530 | 2796*1670*1750 | 2260 |
ESL0514 | 14 | 500 | 2812*1530 | 3067*1730*1810 | 2400 |
ESL0516 | 16 | 500 | 2812*1600 | 3067*1800*2080 | 3500 |
ESL0518 | 18 | 500 | 3070*1600 | 3321*1810*2080 | 3900 |
1000kg Load muaj peev xwm | |||||
ESL1004 | 4 | 1000 | 2100*1200 | 2250*1350*1180 | 1250 |
ESL1006 | 6 | 1000 | 2100*1200 | 2200*1350*1300 | 1400 |
ESL1008 | 8 | 1000 | 2100*1200 | 2200*1350*1420 | 1585 |
ESL1010 | 10 | 1000 | 2100*1200 | 2200*1350*1530 | 1700 |
ESL1012 | 12 | 1000 | 2550*1530 | 2796*1670*1750 | 2560 |
ESL1014 | 14 | 1000 | 2812*1530 | 3067*1750*1810 | 2765 |
1500kg Load muaj peev xwm | |||||
ESL1506 | 6 | 1500 | 2100*1530 | 2250*1750*1530 | 1780 |
ESL1508 | 8 | 1500 | 2100*1530 | 2250*1750*1690 | 2070 |
ESL1510 | 10 | 1500 | 2100*1530 | 2250*1750*1850 | 2250 |
ESL1512 | 12 | 1500 | 2550*1530 | 2250*1762*1850 | 2900 |
ESL1514 | 14 | 1500 | 2816*1600 | 3045*1852*1960 | 3400 |
2000kg Ntsaws muaj peev xwm | |||||
ESL2006 | 6 | 2000 | 2100*1530 | 2250*1750*1530 | 1780 |
ESL2008 | 8 | 2000 | 2100*1530 | 2250*1750*1690 | 2070 |
ESL2010 | 10 | 2000 | 2100*1530 | 2250*1750*1850 | 2250 |
ESL2012 | 12 | 2000 | 2550*1600 | 2796*1852*1954 | 3200 |
ESL2014 | 14 | 2000 | 2816*1600 | 3067*1852*2230 | 3900 |
