| Qauv nab npawb | MSL06 | MSL08 | MSL 10 | MSL 12 | |
| Max platform qhov siab | mm | 6000 | 8000 | 10000 | 11800 |
| Max ua haujlwm siab | mm | 8000 | 10000 | 12000 | 13800 |
| Load peev | kg | 300 | 300 | 300 | 300 |
| Qhov siab tshaj plaws thaum kaw (guardrail sawv ntsug) | mm | 2150 | 2275 | 2400 | 2525 |
| Qhov siab tshaj plaws thaum kaw (guardrail tshem tawm) | mm | 1190 | 1315 | 1440 | 1565 |
| Tag nrho ntev | mm | 2400 | 2400 | 2400 | 2400 |
| Tag nrho qhov dav | mm | 1150 | 1150 | 1150 | 1150 |
| Platform loj | mm | 2270x1150 | 2270x1150 | 2270x1150 | 2270x1150 |
| Extended platform Length | mm | 900 | 900 | 900 | 900 |
| Yam tsawg kawg nkaus hauv av clearance (kaw lub xeev) | mm | 110 | 110 | 110 | 110 |
| Yam tsawg kawg nkaus hauv av clearance (lifting state) | mm | 20 | 20 | 20 | 20 |
| Wheelbase | mm | 1850 | 1850 | 1850 | 1850 |
| Yam tsawg kawg nkaus tig vojvoog (lub log sab hauv) | mm | 0 | 0 | 0 | 0 |
| Yam tsawg kawg nkaus tig lub vojvoog (lub log sab nraud) | mm | 2100 | 2100 | 2100 | 2100 |
| txav ceev (kaw lub xeev) | km/h | 3.5 | 3.5 | 3.5 | 3.5 |
| txav ceev (lifting xeev) | km/h | 0.8 | 0.8 | 0.8 | 0.8 |
| Nce / poob ceev | sec | 70/80 | 70/80 | 70/80 | 70/80 |
| Roj teeb | V/Ah | 4x6/210 | 4x6/210 | 4x6/210 | 4x6/210 |
| charger | V/A | 24/25 | 24/25 | 24/25 | 24/25 |
| Kev nce toj siab tshaj plaws | feem pua | 20 | 20 | 20 | 20 |
| Ua haujlwm siab tshaj plaws tso cai rau lub kaum sab xis | / | 2-3 degree | 2-3 degree | 2-3 degree | 2-3 degree |
| Tsav | / | Ob chav pem hauv ntej log | |||
| Hydraulic nres log | / | Ob chav rear log | |||
| Lub log loj | / | Φ381x127 | Φ381x127 | Φ381x127 | Φ381x127 |
| ncua lub platform load peev | kg | 113 | 113 | 113 | 100 |
| Net nyhav | kg | 1900 | 2080 | 2490 | 2760 |
Nta ntawm tus kheej-propelled txiab nqa:
Tus kheej-propelled txiab nqa nws tus kheej muaj nuj nqi, thiab tuaj yeem taug kev, thim rov qab thiab tig tau ywj pheej yam tsis muaj hluav taws xob sab nraud lossis lub zog traction hauv kev ua haujlwm. Yooj yim txav, ua haujlwm yooj yim, nqa dawb, ua haujlwm ib leeg, nws tuaj yeem ua tiav!
Lub tshuab hluav taws xob tswj qhov chaw ntawm tus kheej-propelled txiab nqa platform txais German thiab American Cheebtsam, hydraulic system txais cov khoom Italian, lub cev muaj zog txais American White hom, lub cev muaj zog txais Canadian Meters hom, thiab lub cev valve txais Taiwan Winner; kev pab cuam lub neej yog ntev thiab qhov tsis ua hauj lwm txij nkawm tus nqi qis.
Qhov zoo ntawm tus kheej-propelled txiab platform:
1. Cov khoom steel phaj platform muaj qhov tsis muaj qhov tsis zoo.
2. Cov khoom steel guardrail yog ruaj. Qhov kawg telescopic khiav yog txuas ntxiv kom haum rau cov khoom loj dua.
3. Pivot dawb los ntawm lubrication thiab txij nkawm.
4. Lub tshuab nqa txiab muaj ib qho kev txhim kho lanyard.
5. Ergonomic joystick maub los uas tuaj yeem ua haujlwm ntawm lub platform lossis hauv av.
6. Tsis tshua muaj suab nrov tso cai rau cov neeg ua haujlwm ua haujlwm hauv qhov chaw ua haujlwm ntsiag to.
7. Lub kaum sab xis loj steering system muab zoo heev maneuverability.
8. Swing-out roj teeb lub thawv thiab lub zog module muab kev yooj yim rau cov khoom siv.
9. Lub cev muaj zog tsis sib xws ua kom lub neej ntev ntawm lub roj teeb thiab lub cev muaj zog, vim tias lub cev muaj zog sib txawv tsuas yog siv lub zog tsim nyog rau kev ua haujlwm.
10. Cov cuab yeej kuaj xyuas qhov yuam kev ntawm lub tsheb ua haujlwm tuaj yeem ceeb toom rau tus neeg teb xov tooj ntawm qhov ua yuam kev.
