Loj |
L1 (cm) | 70-140 |
| L2 (cm) | 60-130 | |
| L3 (cm) | 50 | |
| W 1 (cm) | 50-100 | |
| W 2 (cm) | 40-90 | |
| W 3 (cm) | 80-1400 | |
| W 4 (cm) | 80 | |
| H1 (cm) | 30cm txog 1000cm (customized) | |
| hluav taws xob | 110V/220V/240V/380V/410V (50/60HZ) | |
| Tsav | 1.5KW rau 5KW | |
| Sab laug qhov rooj | YOG/NO | |
| Txoj cai qhov rooj | YOG/NO | |
| Pem teb qhov rooj | YOG/NO | |
| Pem teb tswj | YOG/NO | |
| Tsis siv neeg ramp | YOG/NO | |
| Load peev | 300 KG | |
| Platform hom | Qauv tsis yog- plam hlau phaj | |
| Nyob rau hauv thiab tawm kev taw qhia | 90℃lossis 180℃(kev cai) | |
| Ua haujlwm ib puag ncig | Sab hauv thiab sab nraum zoov | |
| ua haujlwm kub | -20℃- 60 degree | |
| Kev teeb tsa hom | Tsis muaj lub hauv paus pit installation (tso ncaj qha rau hauv av pob zeb) | |
| Thaum muaj xwm ceev nres khawm | Nias lub khawm hloov ceev kom tswj lub tshuab khiav, nce lossis poob | |
| Aluminium alloy bar |
Thaum lub platform txo qis yuav tsum tsis txhob khiav tam sim ntawd thaum nws ntsib teeb meem. |
|
Thaum lub lifting qhov siab ntawm lub rooj zaum nqa lub rooj zaum siab tshaj 3 meters, tag nrho qhov siab ntawm txoj kev tsheb ciav hlau yuav tshaj 4 meters. Txhawm rau kom yooj yim rau kev thauj mus los, phau ntawv qhia kev tsheb ciav hlau feem ntau yog txiav rau hauv ob ntu. Ua raws li cov lus qhia kev tsheb ciav hlau sib txuas ntawm lub rooj zaum nqa lub log yog ib qho teeb meem kev teeb tsa thiab kev saib xyuas. Qhov no feem ntau yog tshwm sim los ntawm kev sib raug zoo, kev sib koom ua ke, lossis ib puag ncig yam. Cov kauj ruam hauv qab no tuaj yeem siv los daws qhov teeb meem no:
1. Txiav txim qhov hauv paus
Ua ntej yuav daws qhov teeb meem ntawm lub log ntawm lub rooj zaum nqa, nws yog ib qho tsim nyog los txiav txim siab qhov ua rau ntawm qhov nplaum. Nyob rau lub sijhawm no, lub vaj huam sib luag zoo nkauj aluminium alloy rau ntawm qhov chaw ntawm lub rooj zaum lub rooj zaum yuav tsum tau muab tshem tawm los soj ntsuam qhov ua rau ntawm qhov sib txuas ntawm cov lus qhia kev sib txuas. Cov teeb meem feem ntau yog:
Misalignment ntawm sab sauv thiab sab hauv phau ntawv qhia kev tsheb ciav hlau (feem ntau)
Lub hauv paus lossis phab ntsa mounting cov ntsiab lus tsis yog perpendicular
Deformation ntawm cov kev taw qhia rail xaus thaum lub sij hawm thauj los yog installation
Kev ua haujlwm tsis raug lossis burrs ntawm kev sib txuas
Loose los yog overtightened txuas bolts ua rau kev taw qhia rail deformation
2. Kho lub rooj zaum nqa lub rooj zaum taw qhia Rail kev sib txuas rau kev sib txuas ntawm txoj hlua
Me ntsis loosen cov ntawv qhia kev tsheb ciav hlau txuas kom tso cai rau qee qhov kev txav ntawm cov ntsia hlau. Ua kom tiav cov seem sab sauv thiab qis ntawm txoj kev tsheb ciav hlau (rau tsev neeg lub rooj zaum lub rooj zaum nqa, qhov kev sib txawv ntawm qhov kev sib txuas yuav tsum yog tsawg dua lossis sib npaug li 0.5 hli), thiab tom qab ntawd rov ua dua -tighten cov connectors. Ua ib qho kev xeem lifting ntawm lub nqa. Yog tias qhov nplaum ploj lawm, nws yog qhov zoo tshaj plaws los ua cov vuam yooj yim rau sab nraud ntawm cov lus qhia kev tsheb ciav hlau sib txuas kom tiv thaiv cov kev taw qhia kev tsheb ciav hlau los ntawm kev xoob thiab ua rau rov ua dua.
3. Tshawb xyuas thiab kho lub log tsheb nqa nqa txoj kev tsheb ciav hlau sib txuas
Yog tias qhov teeb meem tsis tuaj yeem daws tau los ntawm kauj ruam ob, cov lus qhia rail txuas yuav tsum tau muab tshem tawm thiab kuaj xyuas rau:
Burrs, vuam slag, xim tsub zuj zuj, ntug deformation, thiab lwm yam.
Yog tias cov teeb meem no tshwm sim, lawv yuav tsum tau ntxuav, thiab tom qab ntawd rov ua ob kauj ruam.
Tsis txhob dhau- sib tsoo, vim qhov no yuav cuam tshuam rau lub zog thiab kev taw qhia qhov tseeb ntawm txoj kev tsheb ciav hlau.
4. Txheeb xyuas qhov xwm txheej ntawm lub log lub rooj zaum nqa nqa cov menyuam / sliders
Deformation los yog kev puas tsuaj rau cov kev taw qhia Cheebtsam feem ntau exacerbates qhov teeb meem sticking. Tshawb xyuas qhov hnav tsis sib xws thiab lwm yam teeb meem. Tom qab kev tshuaj xyuas, siv cov roj nplua nyeem rau cov lus qhia sliders. 5. Tshawb xyuas lub hauv paus thiab cov fasteners
Xyuas kom meej tias cov phab ntsa lossis cov kab txhawb nqa uas lub rooj zaum nqa lub rooj zaum tau teeb tsa yog ntsug thiab cov ntsia hlau tsis muaj qhov sib tw ua ntu zus. Yog tias ntsia rau ntawm pob zeb, paub meej tias tsis muaj kev tawg nyob rau hauv ib feem ntawm txoj kev tsheb ciav hlau. Qee zaum, refastening los yog ntxiv cov kev txhawb nqa nruab nrab ntawm cov pob qij txha tuaj yeem daws qhov teeb meem.
7. Ua cov khoom thauj thiab kev ua haujlwm
Tom qab daws qhov teeb meem, khiav lub nqa yam tsis muaj kev thauj khoom ua ntej, thiab tom qab ntawd khiav nws hauv qab qhov ntsuas load.
Saib xyuas seb lub rooj zaum lub rooj zaum lub rooj zaum muaj qhov nrawm, txawm tias muaj suab nrov ntawm cov pob qij txha, thiab seb puas muaj kev tiv thaiv tam sim lossis kev co. Lub platform yuav tsum txav mus los ntawm cov pob qij txha, thiab qhov ceev yuav tsum tsis txhob hloov pauv.
