Cov Kev Qhia Rail nqa nqa yog txoj kev nqa khoom ntsug tsim qauv tsim los thauj cov khoom ntawm cov plag tsev. Cov txheej txheem tseem ceeb ntawm cov kab ke no suav nrog cov kev qhia kev qhia, lub chaw ua haujlwm, nqa khoom siv kev nyab xeeb. Hauv qab no yog cov ncauj lus kom ntxaws tawg ntawm yuav ua li cas cov lus qhia kev rails thiab lifting platform tau txuas nrog thiab cuam tshuam kom muaj kev nyab xeeb thiab kev ua haujlwm ruaj khov.
1. Coj ncaj qha: Txoj Kev Ntsug Txoj Kev Ntsug
Cov kev qhia kev qhia muab cov kev coj ua ruaj khov, tswj tau txoj hauv kev rau lub neej phev. Lawv ib txwm ua los ntawm cov hlau thiab muaj kev ruaj ntseg rau lub tsev muaj kev txhim kho lossis cov qauv txhawb nqa.
Cov Hom Ntawm Cov Kev Qhia Rails:
T-puab cov ntsia hlau - feem ntau yog siv rau cov ntawv thov hnyav-, muab kev ruaj khov zoo.
Shadangular lossis C-Zoo li tus ciav hlau - siv nyob rau hauv qee yam tsim kom haum rau cov kev xav tau platform sib txawv.
Hloov cov rails - siv hauv cov khoom me me lossis ua haujlwm.
Qhia Rail Installation:
- Mounted ntsug raws li kev nqa tus ncej siv nkhaus thiab thauj tog rau nkoj bolts.
- Muab tso rau ob sab ntawm lub neej lifting platform kom ntseeg tau tias muaj kev tawm tsam.
- Qhov kev ncua deb ntawm kev qhia cov nqaj yog ua tib zoo ntsuas kom phim lub platform loj thiab load-coj tau muaj peev xwm.
2. Lifting platform: Tus qauv hloov
Lub neej sam thiaj li yog ib feem ntawm kev nqa uas nqa cov khoom thauj. Nws txuas nrog thiab txav mus raws cov kev qhia kev sib txuas siv cov kev sib xyaw ntawm cov yob, coj khau, thiab txhawb nqa ntas.
Cov Ntsiab Lus Ntawm Lub Lifting platform:
Ncej lub ntsiab: ib tug muaj zog steel qauv uas tuav lub platform lawj.
Platform lawj: qhov saum npoo uas nqa khoom tso.
Chais lossis Cov Khau Qhuab Qhia: Cov khoom siv no xaub raws cov kev coj ua kom txo kev sib txhuam thiab tiv thaiv kev sib txhuam.
3. Kev sib txuas mechanism ntawm cov lus qhia kev ntsia thiab platform
Lub neej lub zog txuas nrog cov lus qhia kev siv hlua siv ob qhov tseem ceeb:
(A) chais / coj khau
Cov menyuam los yog cov khau khau tau mounted ntawm ob sab ntawm lub lipa lub zog.
- Cov txiv neej no haum kom nruj rau hauv cov lus qhia kev sib tw, ua kom muaj kev txav mus los nrog qhov tsawg kawg nkaus (sab-rau ib sab.
Cov khoom siv ntawm cov menyuam: feem ntau ua los ntawm cov hlau tawv tawv lossis nylon kom txo tau cov kev hnav thiab kua muag.
Muaj nuj nqi: Cov ntaub pua menyuam yob thiab sau rau ntawm cov kev coj qhia kev sib tw, tso cai rau lub platform txav ntsug hauv txoj kab ncaj nraim.
(B) Lifting tshuab txuas
Lub cuab tam txav mus nce thiab sau rau ntawm cov kev coj qhia kev siv ib qho ntawm cov txheej txheem hauv qab no:
1. Lub tog raj kheej hydraulic (feem ntau)
- Lub tog raj kheej hydraulic yog mounted rau hauv qab lossis sab ntawm lub platform.
- Lub tog raj kheej thawb lub platform nce mus thaum rov ua dua nws.
- Qhia cov rails kom ntseeg tau qhov sib ntsug ntawm lub platform.
2. Hlau saw lossis cov hlau hlua Hoisting System
- Hnyav-Ua Haujlwm Hlau Chain lossis Ropes hlau txuas nrog lub platform.
- Cov saw txuas hla dhau pulleys thiab yog tsav los ntawm hluav taws xob lub cev muaj zog.
- Qhia cov ciav hlau tiv thaiv kev sib tw thiab ua kom lub platform mus rau hauv txoj kab ncaj.
3. Ntsia Hlau Tsav Txheej Txheem (tsis tshua muaj)
- Ib cov hlau txhuas cov mechanism txav lub platform raws cov kev qhia kev qhia.
- Ntsia hlau txoj kev sib hloov txav lub platform nce thiab nqis.
4. Kev ruaj ntseg nta hauv phau ntawv qhia kev tsheb ciav hlau-platform txuas
Txij li cov zaub mov nqa feem ntau nqa cov nra hnyav, ntau txheej txheem kev nyab xeeb kom muaj kev ruaj khov thiab tiv thaiv kev sib tsoo.
A) tiv thaiv kev nyab xeeb khoom siv
- Yog tias lub tshuab ua tsis tau tshwm sim, qhov ntsuas phoo kev nyab xeeb koom nrog cov kev qhia kev thaiv kom nres lub platform los ntawm kev poob.
(B) Txwv tsis pub hloov chaw
- Tso raws li cov lus qhia kev sib tw kom cia li nres lub platform ntawm txoj haujlwm raug.
(C) Counterweight system (yeem)
- Qee qhov nqa cov neeg ua txhaum cai siv cov kev coj ua kom sib npaug rau kev sib npaug ntawm lub platform thiab txo cov khoom thauj ntawm lub cev muaj zog.
Cov kev qhia kev coj ua thiab lub txhab nyiaj hauv nqa cov nqa khoom thauj tau yooj yim siv cov ntaub lossis cov khau muag, ua kom ncaj qha ntsug txav. Lub platform yog nqa los ntawm hydraulic kheej kheej, cov saw, lossis cov hlua hlau, thaum kev nyab xeeb lub cev tiv thaiv kev sib tsoo. Cov teeb tsa no muab cov kev ruaj khov, ua tau zoo, thiab muaj kev nyab xeeb nqa daws kev daws teeb meem ntawm cov plag tsev.
